Hydraulic Valve 4WE6D6X/OFEG24N9EK4/V 4WE6HB62/EG24N9K4 4WE6D7X/HG24N9K4 4WE6D62/OFEG24N9K4 Solenoid Valve

Name: Hydraulic Valve 4WE6D6X/OFEG24N9EK4/V 4WE6HB62/EG24N9K4 4WE6D7X/HG24N9K4 4WE6D62/OFEG24N9K4 Solenoid Valve
Brand: BETTER PARTS Machinery Co., Ltd.
SKU: 4we6d62_eg24n99k4
Price: 80.00 USD
Availability: InStock

Détails de produit

Lieu d'origine: Chine

Nom de marque: BTPS/Rexroth

Numéro de modèle: 4we6d62_eg24n99k4

Conditions de paiement et d'expédition

Quantité de commande min: 5

Prix: Négociable

Détails d'emballage: Boîte/boîte en bois

Délai de livraison: 5 jours de travail

Conditions de paiement: T/T

Capacité d'approvisionnement: 1000/week

Obtenez le meilleur prix

Détails de produit

Description de produit

Détails de produit

Mettre en évidence:
                                                                                                                                                                                                                                                                                Rexroth hydraulic solenoid valve, 4WE6D6X hydraulic valve with warranty, EG24N9K4 compatible hydraulic valve


Matériel:	Casting, alliage en aluminium	Taper:	Vannes, valve de commande hydraulique, rexroth
Appliion:	ingénierie,exploitation minière	Pression:	Haute pression, pression moyenne
Standard ou non standard:	Standard	Pouvoir:	Hydraulique,hydraulique/pneumatique
Température des supports:	Température moyenne, température élevée

Matériel:	Casting, alliage en aluminium
Taper:	Vannes, valve de commande hydraulique, rexroth
Appliion:	ingénierie,exploitation minière
Pression:	Haute pression, pression moyenne
Standard ou non standard:	Standard
Pouvoir:	Hydraulique,hydraulique/pneumatique
Température des supports:	Température moyenne, température élevée

Description de produit

BTPS Hydraulic Directional Control Solenoid valve 4WE series 4WE6 4WE6D 4WE6D62/EG24N9K4 R900561274 hydraulic valve

Factory sale Rexroth Valves 4WE6A 4WE6B 4WE6C 4WE6D 4WE6E 4WE6F 4WE6J 4WE6H 4WE6G 4WE6L 4WE6M 4WE6 4WE10 Hydraulic Valve

Parameter		Data
Weight	Valve with a coil(kg)	Single connection	Centering connection
		3.9	4.0
	Valve with two coils(kg)	5.5	5.6
Installation loion		Arbitrary
Ambient temperature range	Standard model (℃)	-20⋯+70(NBR seal) -15⋯+70 (FKM seal)
	Models suitable for HFC hydraulic oil(℃)	-20⋯+50
	Low temperature model(℃)	-40⋯+50
Storage temperature range(℃)		-20⋯+50
Maximum operating pressure	Port A, B, P(bar)	350
	Port T(bar)	210
Maximum flow(l/min)		160
Hydraulic oil temperature range (at the valve working port)(℃)		–20 … +80 (NBR seal)
		–15 … +80 (FKM seal)
		–20 … +50(HFC hydraulic oil)
		–40 … +50(Low temperature model)
Viscosity range(mm2/s)		2.8 … 500

Rexroth hydraulic valve

A hydraulic valve is an automation component operated by pressure oil. It is controlled by a pressure distribution valve and
pressure oil. It is usually used in combination with an electromagnetic pressure distribution valve. It can be used to remotely
control the on and off of the oil, gas, and water pipeline systems of hydropower stations. Commonly used for clamping, control,lubriion and other oil circuits. There are direct-acting type and pilot type, and the pilot type is mostly used.

Hydraulic valve design principle

The design of the hydraulic valve is mainly for the design of the hydraulic valve group, and the oil circuit must be considered before the design of the hydraulic valve group. It is necessary to determine in advance which parts of the oil circuit can be integrated. The design of the oil circuit must be simple and save Go unnecessary steps. After determining the oil circuit, the main thing is the oblique hole and the process hole. These things in the oil path should be reduced. As long as it is enough, it
is not necessary too much. Pay attention to the hole diameter in the design of the oblique hole and the process hole.

Collecting valve	Proportional valve	Maintaining valve
Throttle valve	Relief valve	Solenoid directional valve
Speed regulation valve	Pressure reducing valve	Manual reversing valve
Drive valve	Pressure valve	Check valve
Flow valve	Cartridge valve	Hydraulic control one-way valve
Collecting valve	Stop valve	Solenoid valve
Pilot valve	Reverse check valve	Superposition valve
Direct acting relief valve	Pilot check valve	Directional valve
Pilot relief valve	Sequence valve	Pilot sequence valve
Pilot reducing valve	Balance valve	Direct acting sequence valve

Features

▶ High-power solenoid

▶ Porting pattern according to DIN 24340 form A

▶ Porting pattern according to ISO 4401-03-02-0-05 andNFPA T3.5.1 R2-2002 D03

▶ Wet-pin DC or AC solenoids with detachable coil

▶ Solenoid coil can be rotated by 90°

▶ The coil can be changed without having to open thepressure-tight chamber

▶ Electrical connection as individual or central connection

▶ Manual override, optional

▶ Spool position monitoring, optional

High Performance Replacement Reexroth Hydraulic Pump Solenoid valve Directional Control Valve 4WE6062-EG24N9K4

The Hydraulic Solenoid Operated Selector Valves come in both 12VDC and 24VDC. These valves come with a nominal flow of either

50LPM or 90LPM and have a maximum pressure of 315 bar.

---- Stack up to 3 sections (A,B type)
----12V/24V DC optional
----3-pin or 2-pin water-proof plug optional

4WE 4WE6 24V Hydraulic Directional Control Valve R900561274 4WE6D62/EG24N9K4 4WE6D70/HG24N9K4

R901391204 4WE 10 Y11-5X/HG24N9K4/M
R901391202 4WE 10 Y5X/HG24N9K4/M
R901391202 4WE 10 Y5X/HG24N9K4/M
R900561272 4WE 6 C6X/EG24N9K4
R900561272 4WE 6 C6X/EG24N9K4
R901089245 4WE 6 C7X/HG24N9K4
R901089245 4WE 6 C7X/HG24N9K4
R900574632 4WE 6 D6X/EG24K4QMBG24
R900574632 4WE 6 D6X/EG24K4QMBG24
R900561274 4WE 6 D6X/EG24N9K4
R900561274 4WE 6 D6X/EG24N9K4
R900909559 4WE 6 D6X/EW230N9K4
R900917825 4WE 6 D6X/EW230N9K4/V
R901087088 4WE 6 D7X/HG24N9K4
R901087088 4WE 6 D7X/HG24N9K4
R900561278 4WE 6 E6X/EG24N9K4
R900561278 4WE 6 E6X/EG24N9K4
R900912492 4WE 6 E6X/EW230N9K4
R901087087 4WE 6 E7X/HG24N9K4
R901087087 4WE 6 E7X/HG24N9K4
R900561280 4WE 6 EA6X/EG24N9K4
R901108712 4WE 6 EA7X/HG24N9K4
R901108712 4WE 6 EA7X/HG24N9K4
R900933648 4WE 6 F6X/EG24N9K4
R900561282 4WE 6 G6X/EG24N9K4
R900561282 4WE 6 G6X/EG24N9K4
R900561286 4WE 6 H6X/EG24N9K4
R900561286 4WE 6 H6X/EG24N9K4
R900561288 4WE 6 J6X/EG24N9K4
R900561288 4WE 6 J6X/EG24N9K4
R901089241 4WE 6 J7X/HG24N9K4
R901089241 4WE 6 J7X/HG24N9K4
R901108702 4WE 6 JA7X/HG24N9K4
R900901751 4WE 6 L62/EG24N9K4
R900901751 4WE 6 L6X/EG24N9K4
R900577475 4WE 6 M6X/EG24N9K4
R900577475 4WE 6 M6X/EG24N9K4
R900572785 4WE 6 U6X/EG24N9K4
R900940418 4WE 6 Y11-6X/EG24N9K4
R900561276 4WE 6 Y6X/EG24N9K4
R900561276 4WE 6 Y6X/EG24N9K4
R901089243 4WE 6 Y7X/HG24N9K4
R901089243 4WE 6 Y7X/HG24N9K4
R900593277 4WE10 C3X/CG24N9K4
R900588201 4WE10 E3X/CG24N9K4
R900594277 4WE10 G3X/CG24N9K4
R900597986 4WE10 H3X/CG24N9K4
R900707281 4WE10 M3X/CG24N9K4
R900595531 4WE10 Y3X/CG24N9K4
R900912496 4WE10D3X/CW230N9K4
R901278763 4WE10D5X/OFEG24N9K4/M
R900911869 4WE10E3X/CW230N9K4
R901278762 4WE10H5X/EG24N9K4/M
R900911868 4WE10J3X/CW230N9K4
R900909559 4WE6D6X/EW230N9K4
R900912492 4WE6E6X/EW230N9K4
R900912493 4WE6G6X/EW230N9K4
R900912494 4WE6H6X/EW230N9K4
R900911762 4WE6J6X/EW230N9K4
R900943462 4WEH 10 D46/6EG24N9ETK4/B10
R900952630 4WEH 10 E4X/6EG24N9ETK4/B10 R900561180 3WE 6 A6X/EG24N9K4
R900592014 3WE10 A5X/EG24N9K4/M
R901391203 4WE 10 C5X/HG24N9K4/M
R901391203 4WE 10 C5X/HG24N9K4/M
R901278760 4WE 10 D5X/EG24N9K4/M
R901278760 4WE 10 D5X/EG24N9K4/M
R901391200 4WE 10 D5X/HG24N9K4/M
R901391200 4WE 10 D5X/HG24N9K4/M
R901432612 4WE 10 D5X/HG24N9K4QYBG24/M
R901278761 4WE 10 E5X/EG24N9K4/M
R901390857 4WE 10 E5X/HG24N9K4/M
R901390857 4WE 10 E5X/HG24N9K4/M
R901391198 4WE 10 EA5X/HG24N9K4/M
R901391198 4WE 10 EA5X/HG24N9K4/M
R901391199 4WE 10 EB5X/HG24N9K4/M
R901278781 4WE 10 F5X/EG24N9K4/M
R901427832 4WE 10 G5X/HG24N9K24/M
R901427832 4WE 10 G5X/HG24N9K4/M
R900911868 4WE 10 J3X/CW230N9K4
R901278744 4WE 10 J5X/EG24N9K4/M
R901278744 4WE 10 J5X/EG24N9K4/M
R901401552 4WE 10 J5X/HG24N9K4/M
R901401552 4WE 10 J5X/HG24N9K4/M
R901391161 4WE 10 L5X/HG24N9K4/M
R901391161 4WE 10 L5X/HG24N9K4/M
R901391194 4WE 10 U5X/HG24N9K4/M
R901391194 4WE 10 U5X/HG24N9K4/M

Charge pump	Hydraulic pump parts
Hydraulic pump	Cylinder block	Press pin
Piston motor	Piston shoe	Snap ring
Piston pump	Retainer plate	Coil spring
Gear pump	Ball guide	Disk spring
Charge pump	Valve plate	Barrel washer
Pilot pump	Shoe plate	Oil seal
Vane pump	Bearing plate	Frication plate
Repair OEM parts	Swash plate	Steel plate
Motor spare parts	Drive shaft	Metal
